Polyurethane Elastomer (MDI-Polyester Type) – Durable & Versatile Industrial-Grade Material
Product Overview
Our MDI-Polyester Polyurethane Elastomer series is engineered for superior performance in demanding environments. Utilizing MDI (Methylene Diphenyl Diisocyanate) and polyester polyols, this series offers excellent mechanical properties, outstanding abrasion resistance, and good oil resistance. With a hardness range spanning from rigid 56D to flexible 80A, it provides tailored solutions for high-wear, high-load, and dynamic applications across various industries, from heavy machinery to consumer goods.
Technical Specifications
| Product Series |
MDI polyester |
| model |
M220/56D |
M220/95A |
M220/90A |
M220/85A |
M220/80A |
| NCO% |
9.3 |
9.8 |
8.8 |
6.9 |
5.9 |
| VIS/70C |
800.00 |
850.00 |
1500.00 |
1400.00 |
2000.00 |
| CURATIVE |
BDO |
BDO |
BDO |
BDO |
BDO |
| RATIO |
9.40 |
9.90 |
8.90 |
7.00 |
6.00 |
| POT LIFE |
4MIN |
5MIN |
5MIN |
5MIN |
6MIN |
| HARDNESS |
56D |
95A |
91A |
85A |
80A |
| TENSILE STRENGTH |
50 |
46 |
44 |
45 |
40 |
| ELONGATION |
470 |
550 |
320 |
480 |
600 |
Key Features & Technical Highlights
Balanced Hardness & Flexibility
Spans from rigid (95A) to flexible (75A), suitable for products requiring structural support or impact absorption.
Example: T150/95A is ideal for high-stress rollers, while T150/75A is perfect for soft-grip handles.
Superior Mechanical Properties
Maintains solid tensile strength (up to 55 MPa) and significant elongation (up to 520%), ensuring resilience under mechanical stress and repeated use.
Offers good tear resistance and abrasion resistance, contributing to long product life.
Controlled Processability
Pot life ranges from 3.5 to 18 minutes, providing flexibility for various manufacturing processes, from quick casting to detailed molding.
Viscosity at 70°C is optimized for processing, ranging from 650 to 2500 cP, facilitating easy handling and molding.
Eco-Friendly Advantage (Biodegradability)
The PCL-based structure offers a degree of biodegradability under specific conditions, making it a more sustainable choice for environmentally conscious products.
Industrial & Consumer Applications
| Application Scene |
Recommended Model |
Performance Advantage |
| Heavy-Duty Wheels & Rollers |
M220/56D / M220/95A |
High hardness and tensile strength withstand heavy impact and load without deformation, ideal for forklift wheels and conveyor rollers. |
| Industrial Seals & Gaskets |
M220/90A / M220/85A |
Excellent compression set resistance and oil resistance ensure long-term sealing performance in hydraulic and pneumatic systems. |
| High-Abrasion Lining & Wear Parts |
M220/95A / M220/90A |
Superior abrasion resistance extends service life in mining equipment, slurry pumps, and chute linings. |
| Flexible Couplings & Shock Absorbers |
M220/85A / M220/80A |
High elasticity (480-600% elongation) and resilience effectively absorb vibration and impact energy in machinery. |
| Printing & Coating Rollers |
M220/90A / M220/85A |
Balanced hardness and flexibility provide precise surface contact for uniform ink or coating transfer. |
Why Choose Our MDI-Polyester Elastomer?
- Material Versatility: Suitable for heavy machinery, automotive, oil & gas, material handling, and printing industries.
- Longevity: Offers significantly longer service life compared to conventional rubber, especially in abrasive and oily environments.
- Customization: Adjustable NCO% (5.9–9.8%) and curing ratios allow for precise customization to meet specific equipment and operational requirements.
Technical Support & Services
We provide comprehensive technical support, including material selection guidance and process optimization recommendations. Download our detailed technical datasheet for complete curing parameters and safety handling instructions.
